rgb2hsv - Convert RGB colormap to HSV colormap

Syntax

cmap = rgb2hsv(M)
hsv_image = rgb2hsv(rgb_image)

Description

cmap = rgb2hsv(M) converts an RGB colormap M to an HSV colormap cmap. Both colormaps are m-by-3 matrices. The elements of both colormaps are in the range 0 to 1.

The columns of the input matrix M represent intensities of red, green, and blue, respectively. The columns of the output matrix cmap represent hue, saturation, and value, respectively.

hsv_image = rgb2hsv(rgb_image) converts the RGB image to the equivalent HSV image. RGB is an m-by-n-by-3 image array whose three planes contain the red, green, and blue components for the image. HSV is returned as an m-by-n-by-3 image array whose three planes contain the hue, saturation, and value components for the image.

See Also

brighten, colormap, hsv2rgb, rgbplot

Color Operations for related functions
