Signal Editor Block
Quickly create, edit, and organize input signals of various data types for multiple simulation scenarios using the Signal Editor block. The block allows fast switching between different signal groups for better representation of a simulation scenario and application. Scenarios and signals can be created, plotted, and saved into a MAT-file from the Signal Editor interface that can be accessed from the block configurations. Existing scenarios and signals can also be imported and reorganized from the Signal Editor.
You can add and modify single and multidimensional signals using MATLAB® expressions or by directly working with the tabular signal data. Fixed-point signal creation is also supported. Importing signal data and properties from the Signal Builder block to the Signal Editor block is also supported. After your work is done, a MAT-file with the list of scenarios and respective signals is created and synced to the Signal Editor block by saving the current Signal Editor session.
