Solve initial-boundary value problems for parabolic-elliptic PDEs in 1-D
sol = pdepe(m,pdefun,icfun,bcfun,xmesh,tspan)
sol = pdepe(m,pdefun,icfun,bcfun,xmesh,tspan,options)
A parameter corresponding to the symmetry of the problem. m can be slab = 0, cylindrical = 1, or spherical = 2. | |
A handle to a function that defines the components of the PDE. | |
A handle to a function that defines the initial conditions. | |
A handle to a function that defines the boundary conditions. | |
A vector [x0, x1, ..., xn] specifying the points at which a numerical solution is requested for every value in tspan. The elements of xmesh must satisfy x0 < x1 < ... < xn. The length of xmesh must be >= 3. | |
A vector [t0, t1, ..., tf] specifying the points at which a solution is requested for every value in xmesh. The elements of tspan must satisfy t0 < t1 < ... < tf. The length of tspan must be >= 3. | |
Some options of the underlying ODE solver are available in pdepe: RelTol, AbsTol, NormControl, InitialStep, and MaxStep. In most cases, default values for these options provide satisfactory solutions. See odeset for details. |
sol = pdepe(m,pdefun,icfun,bcfun,xmesh,tspan) solves initial-boundary value problems for systems of parabolic
and elliptic PDEs in the one space variable
and time
. pdefun, icfun, and bcfun are function
handles. See Function Handles in the MATLAB® Programming documentation
for more information. The ordinary differential equations (ODEs) resulting
from discretization in space are integrated to obtain approximate
solutions at times specified in tspan. The pdepe function returns values of the solution on a mesh
provided in xmesh.
Parametrizing Functions, in the MATLAB Mathematics documentation, explains how to provide additional parameters to the functions pdefun, icfun, or bcfun, if necessary.
pdepe solves PDEs of the form:
 | (2-2) |
The PDEs hold for
and
. The interval
must be finite.
can be 0, 1,
or 2, corresponding to slab, cylindrical, or spherical symmetry, respectively.
If
, then
must be >= 0.
In Equation 2-2,
is a flux term and
is a source term. The coupling
of the partial derivatives with respect to time is restricted to multiplication
by a diagonal matrix
. The diagonal elements of this matrix are either
identically zero or positive. An element that is identically zero
corresponds to an elliptic equation and otherwise to a parabolic equation.
There must be at least one parabolic equation. An element of
that corresponds
to a parabolic equation can vanish at isolated values of
if those values
of
are mesh points. Discontinuities in
and/or
due to material
interfaces are permitted provided that a mesh point is placed at each
interface.
For
and all
, the solution components satisfy initial conditions
of the form
 | (2-3) |
For all
and either
or
, the solution components satisfy
a boundary condition of the form
 | (2-4) |
Elements of
are either identically zero or never zero. Note
that the boundary conditions are expressed in terms of the flux
rather than
. Also, of the
two coefficients, only
can depend on
.
In the call sol = pdepe(m,pdefun,icfun,bcfun,xmesh,tspan):
m corresponds to
.
xmesh(1) and xmesh(end) correspond to
and
.
tspan(1) and tspan(end) correspond to
and
.
pdefun computes the terms
,
, and
(Equation 2-2). It
has the form
[c,f,s] = pdefun(x,t,u,dudx)
The input arguments are scalars x and t and vectors u and dudx that approximate the solution
and its partial derivative with
respect to
, respectively. c, f, and s are column vectors. c stores the diagonal elements of the matrix
(Equation 2-2).
icfun evaluates the initial conditions. It has the form
u = icfun(x)
When called with an argument x, icfun evaluates and returns the initial values of the solution components at x in the column vector u.
bcfun evaluates the terms
and
of the boundary
conditions (Equation 2-4). It has the form
[pl,ql,pr,qr] = bcfun(xl,ul,xr,ur,t)
ul is the approximate solution at the left
boundary xl =
and ur is the
approximate solution at the right boundary xr =
. pl and ql are column vectors corresponding
to
and
evaluated at xl, similarly pr and qr correspond to xr. When
and
, boundedness of the solution near
requires that
the flux
vanish at
. pdepe imposes this boundary condition automatically and it ignores values
returned in pl and ql.
pdepe returns the solution as a multidimensional
array sol.
= ui = sol(:,:,i) is an approximation to the ith component
of the solution vector
. The element ui(j,k) = sol(j,k,i) approximates
at
= (tspan(j),xmesh(k)).
ui = sol(j,:,i) approximates component i of the solution at time tspan(j) and mesh points xmesh(:). Use pdeval to compute the approximation and its partial derivative
at points not
included in xmesh. See pdeval for details.
sol = pdepe(m,pdefun,icfun,bcfun,xmesh,tspan,options) solves as above with default integration parameters replaced by values in options, an argument created with the odeset function. Only some of the options of the underlying ODE solver are available in pdepe: RelTol, AbsTol, NormControl, InitialStep, and MaxStep. The defaults obtained by leaving off the input argument options will generally be satisfactory. See odeset for details.
The arrays xmesh and tspan play different roles in pdepe.
tspan – The pdepe function performs the time integration with an ODE solver that selects both the time step and formula dynamically. The elements of tspan merely specify where you want answers and the cost depends weakly on the length of tspan.
xmesh – Second order approximations
to the solution are made on the mesh specified in xmesh. Generally, it is best to use closely spaced mesh points where the
solution changes rapidly. pdepe does not select the mesh in
automatically. You must provide
an appropriate fixed mesh in xmesh. The cost depends
strongly on the length of xmesh. When
, it is not necessary
to use a fine mesh near
to account for the coordinate singularity.
The time integration is done with ode15s. pdepe exploits the capabilities of ode15s for solving the differential-algebraic equations that arise when Equation 2-2 contains elliptic equations, and for handling Jacobians with a specified sparsity pattern.
After discretization, elliptic equations give rise to algebraic equations. If the elements of the initial conditions vector that correspond to elliptic equations are not "consistent" with the discretization, pdepe tries to adjust them before beginning the time integration. For this reason, the solution returned for the initial time may have a discretization error comparable to that at any other time. If the mesh is sufficiently fine, pdepe can find consistent initial conditions close to the given ones. If pdepe displays a message that it has difficulty finding consistent initial conditions, try refining the mesh.
No adjustment is necessary for elements of the initial conditions vector that correspond to parabolic equations.
Example 1. This example illustrates the straightforward formulation, computation, and plotting of the solution of a single PDE.
This equation holds on an interval
for times
.
The PDE satisfies the initial condition
and boundary conditions
It is convenient to use subfunctions to place all the functions required by pdepe in a single M-file.
function pdex1
m = 0;
x = linspace(0,1,20);
t = linspace(0,2,5);
sol = pdepe(m,@pdex1pde,@pdex1ic,@pdex1bc,x,t);
% Extract the first solution component as u.
u = sol(:,:,1);
% A surface plot is often a good way to study a solution.
surf(x,t,u)
title('Numerical solution computed with 20 mesh points.')
xlabel('Distance x')
ylabel('Time t')
% A solution profile can also be illuminating.
figure
plot(x,u(end,:))
title('Solution at t = 2')
xlabel('Distance x')
ylabel('u(x,2)')
% --------------------------------------------------------------
function [c,f,s] = pdex1pde(x,t,u,DuDx)
c = pi^2;
f = DuDx;
s = 0;
% --------------------------------------------------------------
function u0 = pdex1ic(x)
u0 = sin(pi*x);
% --------------------------------------------------------------
function [pl,ql,pr,qr] = pdex1bc(xl,ul,xr,ur,t)
pl = ul;
ql = 0;
pr = pi * exp(-t);
qr = 1;
In this example, the PDE, initial condition, and boundary conditions are coded in subfunctions pdex1pde, pdex1ic, and pdex1bc.
The surface plot shows the behavior of the solution.
The following plot shows the solution profile at the final value of t (i.e., t = 2).
Example 2. This example illustrates
the solution of a system of PDEs. The problem has boundary layers
at both ends of the interval. The solution changes rapidly for small
.
The PDEs are
where
.
This equation holds on an interval
for times
.
The PDE satisfies the initial conditions
and boundary conditions
In the form expected by pdepe, the equations are
The boundary conditions on the partial derivatives of
have to be written
in terms of the flux. In the form expected by pdepe, the left boundary condition is
and the right boundary condition is
The solution changes rapidly for small
. The program
selects the step size in time to resolve this sharp change, but to
see this behavior in the plots, the example must select the output
times accordingly. There are boundary layers in the solution at both
ends of [0,1], so the example places mesh points near 0 and 1 to resolve these sharp changes. Often some
experimentation is needed to select a mesh that reveals the behavior
of the solution.
function pdex4
m = 0;
x = [0 0.005 0.01 0.05 0.1 0.2 0.5 0.7 0.9 0.95 0.99 0.995 1];
t = [0 0.005 0.01 0.05 0.1 0.5 1 1.5 2];
sol = pdepe(m,@pdex4pde,@pdex4ic,@pdex4bc,x,t);
u1 = sol(:,:,1);
u2 = sol(:,:,2);
figure
surf(x,t,u1)
title('u1(x,t)')
xlabel('Distance x')
ylabel('Time t')
figure
surf(x,t,u2)
title('u2(x,t)')
xlabel('Distance x')
ylabel('Time t')
% --------------------------------------------------------------
function [c,f,s] = pdex4pde(x,t,u,DuDx)
c = [1; 1];
f = [0.024; 0.17] .* DuDx;
y = u(1) - u(2);
F = exp(5.73*y)-exp(-11.47*y);
s = [-F; F];
% --------------------------------------------------------------
function u0 = pdex4ic(x);
u0 = [1; 0];
% --------------------------------------------------------------
function [pl,ql,pr,qr] = pdex4bc(xl,ul,xr,ur,t)
pl = [0; ul(2)];
ql = [1; 0];
pr = [ur(1)-1; 0];
qr = [0; 1];
In this example, the PDEs, initial conditions, and boundary conditions are coded in subfunctions pdex4pde, pdex4ic, and pdex4bc.
The surface plots show the behavior of the solution components.
function_handle (@), pdeval, ode15s, odeset, odeget
[1] Skeel, R. D. and M. Berzins, "A Method for the Spatial Discretization of Parabolic Equations in One Space Variable," SIAM Journal on Scientific and Statistical Computing, Vol. 11, 1990, pp.1-32.
