Planar point vector

A mappoint vector is a container object that holds planar point coordinates
and attributes. The points are coupled, such that the size of the *x*-
and *y*-coordinate arrays are always equal and match the size of any
dynamically added attribute arrays. Each entry of a coordinate pair and associated
attributes, if any, represents a discrete element in the mappoint vector.

`p = mappoint()`

`p = mappoint(x,y)`

`p = mappoint(x,y,Name,Value)`

`p = mappoint(structArray)`

`p = mappoint(x,y,structArray)`

`p = mappoint()`

constructs an empty mappoint vector,
`p`

, with these default property
settings:

p = 0x1 mappoint vector with properties: Collection properties: Geometry: 'point' Metadata: [1x1 struct] Feature properties: X: [] Y: []

`p = mappoint(`

constructs a new mappoint vector and assigns the `x`

,`y`

)`X`

and
`Y`

properties to the numeric array inputs,
`x`

and `y`

.

`p = mappoint(`

constructs a mappoint vector, then adds dynamic properties to the mappoint
vector using `x`

,`y`

,`Name,Value`

)`Name`

, `Value`

argument
pairs. You can specify several name-value pair arguments in any order as
`Name1,Value1,...,NameN,ValueN`

.

`p = mappoint(`

constructs
a new `structArray`

)`mappoint`

vector, assigning the fields of the structure
array, `structArray`

, as dynamic properties. Field values in
`structArray`

that are not numeric values, string scalar,
string array, character vectors, or cell arrays of numeric values or character
vectors are ignored.

`p = mappoint(`

constructs a new `x`

,`y`

,`structArray`

)`mappoint`

vector, sets the
`X`

and `Y`

properties equal to the
numeric arrays `x`

and `y`

, and sets
dynamic properties from the field values of
`structArray`

.

`append` | Append features to geographic or planar vector |

`cat` | Concatenate geographic or planar vector |

`disp` | Display geographic or planar vector |

`fieldnames` | Return dynamic property names of geographic or planar vector |

`isempty` | Determine if geographic or planar vector is empty |

`isfield` | Determine if dynamic property exists in geographic or planar vector |

`isprop` | Determine if property exists in geographic or planar vector |

`length` | Return number of elements in geographic or planar vector |

`properties` | Return property names of geographic or planar vector |

`rmfield` | Remove dynamic property from geographic or planar vector |

`rmprop` | Remove property from geographic or planar vector |

`size` | Return size of geographic or planar vector |

`struct` | Convert geographic or planar vector to scalar structure |

`vertcat` | Vertically concatenate geographic or planar vectors |

If

`X`

,`Y`

, or a dynamic property is set with more values than features in the mappoint vector, then all other properties expand in size using 0 for numeric values and an empty character vector (`''`

) for cell values.If a dynamic property is set with fewer values than the number of features, then this dynamic property expands to match the size of the other properties, by inserting a 0 if the value is numeric or an empty character vector (

`''`

), if the value is a cell array.If the

`X`

or`Y`

property of the mappoint vector is set with fewer values than contained in the object, then all other properties shrink in size.If either

`X`

or`Y`

is set to [ ], then both coordinate properties are set to [ ] and all dynamic properties are removed.If a dynamic property is set to [ ], then it is removed from the object.

The mappoint vector can be indexed like any MATLAB

^{®}vector. You can access any element of the vector to obtain a specific feature. The following examples demonstrate this behavior:
