Nonnegative matrix factorization

`[W,H] = nnmf(A,k)`

[W,H] = nnmf(A,k,* param1*,

`val1`

`param2`

`val2`

[W,H,D] = nnmf(...)

`[W,H] = nnmf(A,k)`

factors the nonnegative *n*-by-*m* matrix `A`

into
nonnegative factors `W`

(*n*-by-`k`

)
and `H`

(`k`

-by-*m*).
The factorization is not exact; `W*H`

is a lower-rank
approximation to `A`

. The factors `W`

and `H`

are
chosen to minimize the root-mean-squared residual `D`

between `A`

and `W*H`

:

D = norm(A-W*H,'fro')/sqrt(N*M)

The factorization uses an iterative method starting with random
initial values for `W`

and `H`

.
Because the root-mean-squared residual `D`

may have
local minima, repeated factorizations may yield different `W`

and `H`

.
Sometimes the algorithm converges to a solution of lower rank than *k*,
which may indicate that the result is not optimal.

`W`

and `H`

are normalized
so that the rows of `H`

have unit length. The columns
of `W`

are ordered by decreasing length.

`[W,H] = nnmf(A,k,`

specifies
optional parameter name/value pairs from the following table.* param1*,

`val1`

`param2`

`val2`

Parameter | Value |
---|---|

`'algorithm'` | Either In general, the |

`'w0'` | An |

`'h0'` | A |

`'options'` | An options structure as created by the `Display` — Level of display. Choices:`'off'` (default) — No display`'final'` — Display final result`'iter'` — Iterative display of intermediate results
`MaxIter` — Maximum number of iterations. Default is`100` . Unlike in optimization settings, reaching`MaxIter` iterations is treated as convergence.`TolFun` — Termination tolerance on change in size of the residual. Default is`1e-4` .`TolX` — Termination tolerance on relative change in the elements of`W` and`H` . Default is`1e-4` .`UseParallel` — Set to`true` to compute in parallel. Default is`false` .`UseSubstreams` — Set to`true` to compute in parallel in a reproducible fashion. Default is`false` . To compute reproducibly, set`Streams` to a type allowing substreams:`'mlfg6331_64'` or`'mrg32k3a'` .`Streams` — A`RandStream` object or cell array of such objects. If you do not specify`Streams` ,`nnmf` uses the default stream or streams. If you choose to specify`Streams` , use a single object except in the case`UseParallel` is`true` `UseSubstreams` is`false`
In that case, use a cell array the same size as the Parallel pool.
To compute in parallel, you need Parallel Computing Toolbox™. |

`'replicates'` | The number of times to repeat the factorization, using
new random starting values for |

`[W,H,D] = nnmf(...)`

also returns `D`

,
the root mean square residual.

[1] Berry, M. W., et al. “Algorithms
and Applications for Approximate Nonnegative Matrix Factorization.” *Computational
Statistics and Data Analysis*. Vol. 52, No. 1, 2007, pp.
155–173.
