McsMatlabDataTools

Version 1.3.1 (854 KB) by Armin Walter
Matlab interface for HDF5 files created by Multi Channel Systems MCS software
5.0
(1)
1.4K Downloads
Updated 24 Aug 2022
View License on GitHub
The McsMatlabDataTools allow you to import HDF5 files created by Multi Channel Systems MCS software into Matlab and offer some basic plotting functions for the data. It supports files exported to HDF5 by the Multi Channel DataManager software and files created by CMOS-MEA-Control and CMOS-MEA-Tools. More information can be found at: http://www.multichannelsystems.com/software/multi-channel-datamanager
http://www.multichannelsystems.com/software/cmos-mea-control
http://www.multichannelsystems.com/software/cmos-mea-tools

Cite As

Armin Walter (2026). McsMatlabDataTools (https://github.com/multichannelsystems/McsMatlabDataTools/releases/tag/1.3.1), GitHub. Retrieved .

MATLAB Release Compatibility
Created with R2022a
Compatible with any release
Platform Compatibility
Windows macOS Linux
Tags Add Tags

+McsHDF5

+McsHDF5/@McsAnalogStream

+McsHDF5/@McsAverageSegment

+McsHDF5/@McsCmosAcquisitionSource

+McsHDF5/@McsCmosDataSource

+McsHDF5/@McsCmosFilterSource

+McsHDF5/@McsCmosLinkedDataSource

+McsHDF5/@McsCmosNetworkExplorerSource

+McsHDF5/@McsCmosRecording

+McsHDF5/@McsCmosSpikeSorterSource

+McsHDF5/@McsCmosSpikeSorterUnit

+McsHDF5/@McsCmosSpikeStream

+McsHDF5/@McsCutoutSegment

+McsHDF5/@McsData

+McsHDF5/@McsEventStream

+McsHDF5/@McsFrameDataEntity

+McsHDF5/@McsFrameStream

+McsHDF5/@McsH5Helper

+McsHDF5/@McsRecording

+McsHDF5/@McsSegmentStream

+McsHDF5/@McsStream

+McsHDF5/@McsTimeStampStream

+McsHDF5/@McsVideo

+McsHDF5/help

+McsHDF5/help

Versions that use the GitHub default branch cannot be downloaded

Version Published Release Notes
1.3.1

See release notes for this release on GitHub: https://github.com/multichannelsystems/McsMatlabDataTools/releases/tag/1.3.1
1.3.0

- Lazy loading of ChannelDataTimeStamps field of AnalogStreams for lower memory usage, especially for long recordings
1.2.2

Connected to Github repository
1.2.1

- Replaced STA Explorer with Network Explorer for compatibility with newest CMOS-MEA-Tools version
- Added McsHDF5.verbosity function to suppress toolbox outputs
1.2.0

- Added plot functions for STA Explorer and Spike Sorter data
- Added new plot options for SegmentStreams
- Bug Fix: Improved compatibility with Matlab R2011a
- Bug Fix: Fixed orientation of Conversion Factor matrix in new CMOS-MEA format
1.1.0.0

Added support for files created by CMOS-MEA-Control and CMOS-MEA-Tools
1.0.3.0

Rows and columns of ConversionFactors in FrameDataEntities were switched
Handled data sub type 'Sweep' in SegmentStreams
1.0.2.0

Fixed bug in FrameDataEntity: Rows and columns were switched
Better handling of 64 Bit numbers for improved compatibility with Matlab R2009a - R2010a
1.0.1.0

Bugfix: Does not attempt to read empty streams.
1.0.0.0
