This 5G tutorial video series explains key concepts behind the 5G New Radio (NR) physical layer standard. You will learn about the requirements and use cases of 5G and the resulting differences between the 5G and LTE standards. Each video offers a deep dive into the technologies and concepts behind 5G NR, including 5G waveforms, frame structure and numerology, downlink and uplink data, Control Resource Sets (CORESETs), demodulation reference symbols (DMRS), synchronization signal blocks (SSB), Cell Search and RACH procedures, and channel estimation.
About the Series | 5G Explained The video outlines the main goals of the "5G Explained" series and introduces the basic configuration of 5G New Radio.
Introduction to 5G NR PHY | 5G Explained Learn about use cases, requirements, some of the main differences between 5G New Radio (NR) and LTE, and deployment scenarios for 5G NR. You’ll also learn about frequency ranges for 5G NR, FR1 and FR2.
5G Waveforms, Frame Structure, and Numerology | 5G Explained Explore the basics behind 5G NR waveforms, frame structure, and numerology. This video also explains how adaptive bandwidth parts help reduce power consumption.
Downlink Data in 5G NR | 5G Explained Learn about downlink data transmission in 5G NR. Explore the downlink shared channel chain, which includes LDPC coding, layer mapping, resource element allocation for PDSCH transmission, PDSCH mapping, and precoding.
Uplink Data in 5G NR | 5G Explained Learn about uplink data transmission in 5G New Radio, which includes elements already found in the downlink shared channel chain including LDPC coding, modulation schemes, layer mapping, the two types of PUSCH mapping, and precoding.
Downlink Control Information in 5G NR | 5G Explained Learn about downlink control information (DCI) in 5G New Radio, including its content, encoding, modulation, and mapping to the 5G New Radio slot via the PDCCH or physical downlink control channel.
CORESET and PDCCH in 5G NR | 5G Explained Learn about CORESETs, to which the physical downlink control channel (PDCCH) gets mapped. The video illustrates CORESETs and PDCCH using an interactive example and shows how search spaces simplify control information decoding.
Uplink Control Information in 5G NR | 5G Explained Learn about uplink control information (UCI) in 5G New Radio, including its content, encoding, modulation, and mapping to the 5G New Radio slot via the PUCCH or physical uplink control channel.
Demodulation Reference Signals in 5G NR | 5G Explained Learn about demodulation reference signals (DMRS) in 5G New Radio, including their use in channel estimation and the different configurations for signal and multi-user MIMO.
Synchronization Signal Blocks in 5G NR | 5G Explained Learn about the synchronization signal block (SSB) in 5G New Radio (NR), which is comprised of the primary and secondary synchronization signals and the broadcast channel. You’ll also learn about its role in synchronization.
Initial Acquisition Procedures in 5G NR | 5G Explained Learn about initial acquisition procedures, including cell search based on the synchronization signal block (SSB), extraction of the master information block (MIB), and the random access procedure.
Signals for Channel Sounding in 5G NR | 5G Explained Learn about the signals in 5G New Radio (NR) that enable channel sounding. Those signals include the channel state information reference signals (CSI-RS) on the downlink and sounding reference signals (SRS) on the uplink.
