Data Converters

Simulate successive-approximation-register (SAR) and flash analog to digital data converters (ADC)

Simulate and analyze performance metrics of analog to digital data converters. Start from complete system-level models of typical ADC architectures, such as SAR or flash ADC. Modify ADC parameters until you reach your desired system specifications. Use Measurements and Testbenches to validate your design.

Blocks

expand all

Sampling Clock SourceGenerate clock signal with aperture jitter
Delta Sigma ModulatorModel a discrete delta sigma modulator ADC
Flash ADCN-bit ADC with flash architecture
SAR ADCN-bit successive approximation register (SAR) based ADC
Binary Weighted DACN-bit DAC based on R-2R weighted resistor architecture
Segmented DACConvert large digital input to analog signal using arrangement of smaller DACs
