Controlled Voltage Source
Ideal voltage source driven by input signal
The Controlled Voltage Source block represents an ideal voltage source that is powerful enough to maintain the specified voltage at its output regardless of the current flowing through the source.
The output voltage is V = Vs, where Vs is the numerical value presented at the physical signal port.
The block has one physical signal input port and two electrical conserving ports associated with its electrical terminals.
C/C++ Code Generation
Generate C and C++ code using Simulink® Coder™.
Introduced in R2007a
