Multimode Variable-Size Signal
This model shows how to use different operation modes to correspond to different signal sizes.
About This Example
Open the example model:
The processing subsystem in this model receives a variable-size signal, where the size of the signal depends on the operation mode of the system. For each mode change, the Mode Control Logic Stateflow® Chart generates a function-call to reset the blocks contained in the Process subsystem.
