Programmatic Tuning

Tune control systems at the command line

You can tune control systems at the command line using the systune command. To do so, use the slTuner interface to configure your Simulink® model for linearization and tuning, specify blocks to tune, and specify analysis points.

The library of tuning goals lets you capture high-level design requirements in a form suitable for fast automated tuning. This library includes standard control objectives such as reference tracking, disturbance rejection, loop shapes, closed-loop damping, and stability margins.
