Frame-Based Sobel Filter for HDL Coder
Version 1.0.0 (137 KB) by
Dr. Kaputa
This Simulink model demonstrates how to perform a frame-based Sobel filter on an input image and allows one to convert to HDL via HDL Coder.
This Simulink model demonstrates how to perform a frame-based Sobel filter on an input image. The convolution kernel can easily be converted to HDL via HDL coder. The conv_core block was successfully converted to a Xilinx AXI Stream IP core and run on the Fusion 2 FPGA stereo imager.
Cite As
Dr. Kaputa (2025). Frame-Based Sobel Filter for HDL Coder (https://github.com/ravvenlabs/simulink-frame-based-sobel-model), GitHub. Retrieved .
MATLAB Release Compatibility
Created with
R2023a
Compatible with any release
