LibHybrid for System Identification Toolbox

version 1.1.0.0 (156 KB) by Matteo Ragni
A wrapper for hybrid system simulation with MATLAB System Identification Toolbox

62 Downloads

Updated 18 Jan 2018

From GitHub

View license on GitHub

# libhybrid - A library for discretized Hybrid Dynamical Systems
This library implements an hybrid system in the form:
Flow map:
t'(k) = 1
j'(k) = 0
x'(t, j) = f(t, j, x(t, j), u(t, j) ,p)
for (t, j, x, u) in C
Jump map:
t(k + 1) = t(k)
j(k + 1) = j(k)
x(t, j + 1) = g(t, j, x(t, j), u(t, j), p)
for (t, j, x, u) in D

where:

* f is the flow map;
* g is the jump map;
* h is the output map;
* C is the flow set;
* D is the jump set.
* p are parameters.
* k is an engine time for the integration of t and j.

The flow map is discretized with a Runge Kutta 4 step. For the evolution of the system, both t and j are limited by horizons.

Cite As

Matteo Ragni (2022). LibHybrid for System Identification Toolbox (https://github.com/MatteoRagni/libhybrid), GitHub. Retrieved .

MATLAB Release Compatibility
Created with R2016b
Compatible with any release
Platform Compatibility
Windows macOS Linux
Acknowledgements

Inspired by: Hybrid Equations Toolbox v2.04
