pid2
Create 2DOF PID controller in parallel form, convert to parallelform 2DOF PID controller
Syntax
C2 = pid2(Kp,Ki,Kd,Tf,b,c)
C2 = pid2(Kp,Ki,Kd,Tf,b,c,Ts)
C2 = pid2(sys)
C2 = pid2(___,Name,Value)
Description
pid2
controller objects represent
twodegreeoffreedom (2DOF) PID controllers in parallel form. Use
pid2
either to create a pid2
controller object from known coefficients or to convert a dynamic system model to
a pid2
object.
Twodegreeoffreedom (2DOF) PID controllers include setpoint weighting on the proportional and derivative terms. A 2DOF PID controller can achieve fast disturbance rejection without significant increase of overshoot in setpoint tracking. 2DOF PID controllers are also useful to mitigate the influence of changes in the reference signal on the control signal. The following illustration shows a typical control architecture using a 2DOF PID controller.
creates a continuoustime 2DOF PID controller with proportional, integral, and
derivative gains C2
= pid2(Kp
,Ki
,Kd
,Tf
,b
,c
)Kp
, Ki
, and
Kd
and firstorder derivative filter time constant
Tf
. The controller also has setpoint weighting
b
on the proportional term, and setpoint weighting
c
on the derivative term. The relationship between the
2DOF controller output (u) and its two inputs
(r and y) is given by:
$$u={K}_{p}\left(bry\right)+\frac{{K}_{i}}{s}\left(ry\right)+\frac{{K}_{d}s}{{T}_{f}s+1}\left(cry\right).$$
This representation is in parallel form. If all
coefficients are realvalued, then the resulting C2
is a
pid2
controller object. If one or more of these
coefficients is tunable (realp
or genmat
),
then C2
is a tunable generalized statespace
(genss
) model object.
creates a discretetime 2DOF PID controller with sample time
C2
= pid2(Kp
,Ki
,Kd
,Tf
,b
,c
,Ts
)Ts
. The relationship between the controller output and
inputs is given by:
$$u={K}_{p}\left(bry\right)+{K}_{i}IF\left(z\right)\left(ry\right)+\frac{{K}_{d}}{{T}_{f}+DF\left(z\right)}\left(cry\right).$$
IF(z) and DF(z) are the discrete integrator formulas for the integrator and derivative filter. By default,
$$IF\left(z\right)=DF\left(z\right)=\frac{{T}_{s}}{z1}.$$
To choose different discrete integrator formulas, use the
IFormula
and DFormula
properties. (See
Properties for more information). If
DFormula
= 'ForwardEuler'
(the default
value) and Tf
≠ 0, then Ts
and
Tf
must satisfy
Tf > Ts/2
. This requirement ensures a stable
derivative filter pole.
converts the dynamic system C2
= pid2(sys
)sys
to a parallel form
pid2
controller object.
specifies additional properties as commaseparated pairs of
C2
= pid2(___,Name,Value
)Name,Value
arguments.
Input Arguments

Proportional gain.
When Default: 1

Integral gain.
When Default: 0

Derivative gain.
When Default: 0

Time constant of the firstorder derivative filter.
When Default: 0

Setpoint weighting on proportional term.
When Default: 1

Setpoint weighting on derivative term.
When Default: 1

Sample time. To create a discretetime
Default: 0 (continuous time)

SISO dynamic system to convert to parallel

NameValue Arguments
Specify optional
commaseparated pairs of Name,Value
arguments. Name
is
the argument name and Value
is the corresponding value.
Name
must appear inside quotes. You can specify several name and value
pair arguments in any order as
Name1,Value1,...,NameN,ValueN
.
Use Name,Value
syntax to set the numerical integration
formulas IFormula
and DFormula
of a
discretetime pid2
controller, or to set other object
properties such as InputName
and
OutputName
. For information about available
properties of pid2
controller objects, see Properties.
Output Arguments

2DOF PID controller, returned as a

Properties

Setpoint weights on the proportional and derivative terms,
respectively.

PID controller gains. Proportional, integral, and derivative gains, respectively.


Derivative filter time constant. The

Discrete integrator formula
IF(z) for the
integrator of the discretetime $$u={K}_{p}\left(bry\right)+{K}_{i}IF\left(z\right)\left(ry\right)+\frac{{K}_{d}}{{T}_{f}+DF\left(z\right)}\left(cry\right).$$
When Default:

Discrete integrator formula
DF(z) for the
derivative filter of the discretetime $$u={K}_{p}\left(bry\right)+{K}_{i}IF\left(z\right)\left(ry\right)+\frac{{K}_{d}}{{T}_{f}+DF\left(z\right)}\left(cry\right).$$
When Default:

Time delay on the system input.

Time delay on the system Output.

Sample time. For continuoustime models, Changing this property does not discretize or resample the model.
Use Default:

Units for the time variable, the sample time
Changing this property has no effect on other properties, and
therefore changes the overall system behavior. Use Default:

Input channel name, specified as a character vector or a 2by1
cell array of character vectors. Use this property to name the input
channels of the controller model. For example, assign the names C.InputName = {'setpoint';'measurement'}; Alternatively, use automatic vector expansion to assign both input names. For example: C.InputName = 'Cinput'; The input names automatically expand to You can use the shorthand notation Input channel names have several uses, including:
Default:

Input channel units, specified as a 2by1 cell array of character
vectors. Use this property to track input signal units. For example,
assign the units C.InputUnit = {'Volts';'mol/m^3'};
Default:

Input channel groups. This property is not needed for PID controller models. Default:

Output channel name, specified as a character vector. Use this
property to name the output channel of the controller model. For example,
assign the name C.OutputName = 'control'; You can use the shorthand notation Input channel names have several uses, including:
Default: Empty character vector,

Output channel units, specified as a character vector. Use this
property to track output signal units. For example, assign the unit C.OutputUnit = 'Volts';
Default: Empty character vector,

Output channel groups. This property is not needed for PID controller models. Default:

System name, specified as a character vector. For example, Default:

Any text that you want to associate with the system, stored as a string or a cell array of
character vectors. The property stores whichever data type you
provide. For instance, if sys1.Notes = "sys1 has a string."; sys2.Notes = 'sys2 has a character vector.'; sys1.Notes sys2.Notes ans = "sys1 has a string." ans = 'sys2 has a character vector.' Default:

Any type of data you want to associate with system, specified as any MATLAB^{®} data type. Default:

Sampling grid for model arrays, specified as a data structure. For model arrays that are derived by sampling one or more independent variables, this property tracks the variable values associated with each model in the array. This information appears when you display or plot the model array. Use this information to trace results back to the independent variables. Set the field names of the data structure to the names of the sampling variables. Set the field values to the sampled variable values associated with each model in the array. All sampling variables should be numeric and scalar valued, and all arrays of sampled values should match the dimensions of the model array. For example, suppose you create a 11by1
array of linear models, sysarr.SamplingGrid = struct('time',0:10) Similarly, suppose you create a 6by9
model array, [zeta,w] = ndgrid(<6 values of zeta>,<9 values of w>) M.SamplingGrid = struct('zeta',zeta,'w',w) When you display M M(:,:,1,1) [zeta=0.3, w=5] = 25  s^2 + 3 s + 25 M(:,:,2,1) [zeta=0.35, w=5] = 25  s^2 + 3.5 s + 25 ... For model arrays generated by linearizing a Simulink^{®} model
at multiple parameter values or operating points, the software populates Default:
Examples
Tips
To design a PID controller for a particular plant, use
pidtune
orpidTuner
. To create a tunable 2DOF PID controller as a control design block, usetunablePID2
.To break a 2DOF controller into two SISO control components, such as a feedback controller and a feedforward controller, use
getComponents
.Create arrays of
pid2
controller objects by:In an array of
pid2
controllers, each controller must have the same sample timeTs
and discrete integrator formulasIFormula
andDFormula
.To create or convert to a standardform controller, use
pidstd2
. Standard form expresses the controller actions in terms of an overall proportional gain K_{p}, integral and derivative times T_{i} and T_{d}, and filter divisor N. For example, the relationship between the inputs and output of a continuoustime standardform 2DOF PID controller is given by:$$u={K}_{p}\left[\left(bry\right)+\frac{1}{{T}_{i}s}\left(ry\right)+\frac{{T}_{d}s}{\frac{{T}_{d}}{N}s+1}\left(cry\right)\right].$$
There are two ways to discretize a continuoustime
pid2
controller:Use the
c2d
command.c2d
computes new parameter values for the discretized controller. The discrete integrator formulas of the discretized controller depend upon thec2d
discretization method you use, as shown in the following table.c2d
Discretization MethodIFormula
DFormula
'zoh'
ForwardEuler
ForwardEuler
'foh'
Trapezoidal
Trapezoidal
'tustin'
Trapezoidal
Trapezoidal
'impulse'
ForwardEuler
ForwardEuler
'matched'
ForwardEuler
ForwardEuler
For more information about
c2d
discretization methods, See thec2d
reference page. For more information aboutIFormula
andDFormula
, see Properties.If you require different discrete integrator formulas, you can discretize the controller by directly setting
Ts
,IFormula
, andDFormula
to the desired values. (See Discretize a ContinuousTime 2DOF PID Controller.) However, this method does not compute new gain and filterconstant values for the discretized controller. Therefore, this method might yield a poorer match between the continuous and discretetimepid2
controllers than usingc2d
.
