Matching Network Design

Design narrowband matching networks

Matching network designs a set of circuits that match the impedance of a given source to the impedance of a give load at a specified center frequency.

Objects

matchingnetworkCreate matching network and generate circuit objects

Functions

addEvaluationParameterAdds performance goal for sort, pass, or fail matching network design
circuitDescriptionsTables describing each created matching network's topology and performance
getEvaluationParametersTable of evaluation parameters currently used to rank and pass or fail matching network designs
clearEvaluationParameterDelete one or more performance goals
exportCircuitsExport selected matching network objects as circuit or rfckt objects for further analysis
circuitDescriptionsTables describing each created matching network's topology and performance
rfplotPlot input reflection coefficient and transducer gain of matching network
smithplotPlot impedance transformation for selected matching network on smith chart
sparametersS-parameter object

Featured Examples
