Simulation and Analysis
This set of steps runs the
soc_hwsw_top.slx model created in the
previous steps. A visual of the processor output data shows the complete SoC
In the project folder, open the model
Using a Scope block and Rate Transition block, update the model as shown in this diagram.
Run the model and open the
The display in the
Vector Scope shows the counter output.
