802.11be (Wi-Fi 7)

Transmit 802.11be™ (EHT) signals

Model EHT-related signal transmission functionality.

Apps

WLAN Waveform GeneratorCreate, impair, visualize, and export WLAN waveforms

Functions

expand all

wlanMACFrameGenerate WLAN MAC frame (MPDU or A-MPDU)
wlanMACFrameConfigConfigure WLAN MAC frame (Since R2019b)
wlanMSDULengthsCalculate MSDU lengths
wlanEHTMUConfigConfigure EHT MU transmission (Since R2022b)
wlanEHTTBConfigConfigure EHT TB transmission (Since R2023a)
numPostFECPaddingBitsRequired number of post-FEC padding bits (Since R2022b)
packetFormat WLAN packet format
psduLengthEHT PSDU length (Since R2022b)
ruInfoResource unit allocation information
compressionModeCompression mode of EHT TB configuration (Since R2023a)
showAllocationResource unit allocation (Since R2019b)
transmitTimePacket transmission time (Since R2022b)
wlanWaveformGeneratorGenerate WLAN waveform
wlanSampleRateNominal sample rate
wlanScrambleScramble and descramble binary input sequence
wlanConstellationMapConstellation mapping
wlanStreamParseStream-parse encoded streams
wlanBCCEncodeConvolutionally encode binary data

Topics

See Also

802.11be (Wi-Fi 7)

Receive 802.11be (EHT) waveforms
