Use Antenna Toolbox™ to design custom PCB antennas for practical designs such as cell phones, RFID, and IoT applications. Prototype and implement simulated PCB antennas by specifying the RF connector suitable for your application and customizing the PCB manufacturing services.
Combine geometrical shapes and mathematical operations to create
unique antenna geometries that meet for your antenna specifications. For
example, you can use these objects and functions in
pcbStack, to create
single or multi-layered PCB-based antenna designs.
|Change the size of the shape by a fixed amount|
|Move shape to new location|
|Rotate shape about axis and angle|
|Rotate shape about X-axis and angle|
|Rotate shape about Y-axis and angle|
|Rotate shape about Z-axis and angle|
|Extract and modify metal layers from |
